PRM 160 FH
3 rolls hydraulic section and pipe bending machine Metallkraft PRM 160 FH – bending by two bottom rolls
Technical specifications:
• Top shaft-Ø 160mm
• Roll-Ø 500mm
• Working speed 3 and 6m/min
• Motor power 22kW / 400V / 50Hz
• Measures 2500mm x 2350mm x 2600mm
• Weight 10700kg
Standard features:
• All rolls powered by hydromotor and planetary gear box
• Hardened and ground shafts
• Hardened standard rolls
• Horizontal and vertical possibilities of working
• Hydraulic bending by two bottom rolls
• Mobile control panel
• Two digital displays for the bottom roll
• Hydraulic lateral rolls in 2 axes (in/out and up/down)
• User’s manual and CE declaration
Kapacitás:
- Lapos acél:
150x40mm átm. 2500mm,
50x10mm átm.700 mm
- Négyszög szelvény tömör:
280x50mm átm. 1500mm,
120x15mm átm.700 mm
- Opcionális görgőkkel:
- Kör szelvény tömör:
átm.90mm átm. 1800mm,
átm.30mm átm.700 mm
- Cső:
átm.180x4mm átm. 4000mm,
átm.60x2mm átm.700 mm
- Zártszelvény:
120x8mm átm. 3000mm,
40x3mm átm.700 mm
